Diablo DB-500.1D

Specifications:

• 1Ch Full-Range Super Mini Class D Amplifier
• RMS POWER@ 14.4V (4 OHM) 225W RMS RMS POWER@ 14.4V (2 OHM) 328W RMS RMS POWER@ 14.4V (1 OHM) 525W RMS
• INPUT SENSITIVITY: 200MV
• Signal-to-Noise Ratio: 97dB Frequency Response:15Hz-10KHz




Crossover:

• H.P.F. (High Pass Filter) 15 to 1 KHz Variable
• L.P.F. (Low Pass Filter) 40 to 10 KHz Variable
• Bass Boost: 0-12dB (50Hz)
• Protection System: Output Short/High/Low Supply
• Voltage/Thermal Protection
• Minimum Supply Voltage: 9V
• Maximum Supply Voltage: 16V
