Sundown Audio U12 V2 12" 2000W RMS Subwoofer DVC

FEATURES

• Black Aluminum 3” voice coil former for superior heat dissipation
• High Temperature Round-Wire ALU voice coil with high-temp black adhesive
• Double stitched surround
• Heavy duty cast baskets – all new, custom-tooled
• Spring loaded terminals accept up to 8 gauge
• Stitched-on double-XL tinsel leads
• Solid pole with vent channels and aluminum shorting ring cap
• Rear drilled gap-venting
• Innovative high-velocity cast aluminum vented frame spacer ring
• Magnet ID shorting ring
• Top-Plate Cooling Channels
• Cast Aluminum surround bolt-on rings
• Optimized for small ported or bandpass enclosures

SPECIFICATIONS

T/S SPECS	UV.2 12" D2	UV.2 12" D4
RE (Ohms)	3.8407	6.0577
FS (Hz)	41.3260	41.9087
VAS (L)	14.7612	14.7535
Qes	0.4862	0.5870
Qms	4.7454	4.9022
Qts	0.4410	0.5242
Le (mH)	3.1858	4.3694
BL (NA)	27.2694	31.1265
Mms (Grams)	358.6438	356.5462
Cms (uM/N)	40.4709	40.4498
Sens (dB @ 1w/1m)	85.1980	84.4191
